TB6600 stepper motor driver NEMA17/23 stepper motor driver woodworking engraving CNC machining 17/23 stepper motor driver upgrad

-
Introduction:


This is a professional two-phase stepper motor drive. Positive and negative control can be implemented, and 7 subdivision controls can be selected through a 3-bit DIP switch Select 8 current controls with 3-position DIP switch Suitable for driving 57, 42 two-phase, four-phase mixing Stepper motor. It can drive motors with low vibration, low noise and high speed.

Current Price


Features:

※ Original new stepper motor driver chip ※ Current is selected by the DIP switch ※ Interface uses high speed optocoupler isolation ※ Seven subdivisions are adjustable ※ Automatic semi-flow reduces heat ※ Large-area heat sink is not afraid of high temperature environment ※ Strong anti-high frequency interference ability ※ Overheating, overcurrent short circuit protection


Electrical parameters:

Input voltage DC9-40V Input current Recommended switching power supply 5A Output current 0.5-4.0A Maximum power consumption 160W Subdivision 1,2/A, 2/B, 4, 8, 16, 32 Temperature Working temperature -10 ~ 45 ° C; storage temperature -40 ° C ~ 70 ° C Moisture, no condensation, no water drops Gases are prohibited from flammable gases and conductive dust Weight 0.2 kg

size:
